Digital Measurement System
-
For Camping-car
Check level on your smartphone
Alugas or Gaslow cylinder
-
For Camping-car
Level measurement
Connected to the DIMES app
LPG Valves
LPG Cylinder Quick-coupling Valves for Camping
-
Inlet: Various threads
Outlet: 35mm to EN15202
Plastic cap available
-
Inlet: Various threads
Outlet: 35mm to EN15202
Sealed dust plug
-
Inlet: Various threads
Outlet: 35mm to EN15202
Pressure tight cap available
-
Inlet: Various threads
Outlet: 35mm to EN15202
Pressure tight cap available
-
Inlet: Various threads
Outlet: 35mm, EN15202
Monobody
-
Inlet: Various threads
Outlet: 16mm to EN15202
Pressure tight plastic cap available
-
Inlet: Various threads
Outlet: 20, 21 or 22mm to EN15202
Pressure tight platic cap available
-
Inlet: Various threads
Outlet: 20mm, 21mm, 22mm
With sealed dust plug
-
Inlet: Various threads
Outlet: 27 mm, EN15202
With dust plug
-
Inlet: 3/4-14 NGT
Outlet: Bayonet connection
Pressure tight plastic cap
LPG Cylinder Handwheel Valves for Camping
-
Inlet: W19.8, DIN 477 (17E)
Outlet: W 21 8x1/14 - LH DIN 477
PRV: 26 or 35 bar
-
Inlet: W28.8, DIN 477 (25E)
Outlet: W21.8/1/14-LH DIN 477
PRV: 26 or 35 bar
-
Inlet & outlet: Various threads
PRV: Without pressure relief valve
Excess Flow Rate / Flow limiter
-
Inlet: W19.8 DIN 477 (17E)
Outlet: R3/8-LH DIN 477 No.4
With diptube
-
Inlet: W28.8 DIN 477 (25E), 3/4” NGT
Outlet: 0.885 NGO
PRV: without
-
Inlet: Various threads
Outlet: 0.885 NGO, 5/8“BSP-LH
PRV: Different settings
-
Inlet: ¾”-14 NGT
Outlet: 0.885 NGO
PRV: 420 / 435 / 450 psi
-
Inlet: ¾“ NPT M 34 x 1,5
Outlet: CGA 510_ 1 5/16“ ACME
PRV: 375 PSI
LPG Multivalves for Camping
-
Inlet: 1 ¼ " NPT
Outlet: 1 ¾ -6 ACME (filling)
Filling connection: Different settings
-
High accuracy
Easy to calibrate
Remote monitoring
LPG Regulators
LPG Quick-coupling Regulators for Camping
-
Low pressure regulator
With RPV
1 kg/hr capacity
-
High pressure Regulator
Adjustable pressure
Lock ring secured regulator
-
Low pressure regulator
With inlet pressure
Dual stage regulator
-
Low pressure regulator
With shutoff valve
Dual stage regulator
-
Low pressure regulator
Single stage regulator
With pressure gauge and shutoff valve
-
Low pressure regulator
Single stage regulator
With shutoff valve
-
Low pressure regulator
Single stage regulator
With pressure gauge and shutoff valve
-
Low pressure regulator
Single-stage regulator
Incorporating shutoff valve
-
High pressure regulator
Adjustable pressure
Additional shut-off valve
-
High pressure regulator
Ultra compact design
Adjustable outlet pressure
-
High pressure regulator
Adjustable outlet pressure
Single stage
-
High pressure regulator
Adjustable pressure
8 kg/hr capacity
-
Low pressure regulator
Single stage
1 kg/hr capacity
-
High pressure
Shut-off valve
No pressure reduction
-
Low pressure regulator
Ultra compact design
With shutoff valve
LPG Screw-on Regulators for Camping
-
Low pressure regulator
Easy installation
50mbar
-
Capacity: 1.5 kg/h
Inlet: W21.8 (G12)
Outlet pressure: 37 mbar
-
Capacity: 1.5 kg/h
Inlet: W21.8 (G12)
Outlet pressure: 50 mbar
-
Capacity: 4 kg/h
Inlet: G5
Outlet pressure: 37 mbar
-
Capacity: 1 kg/h
Inlet: G10
Outlet pressure: 30 mbar
-
Capacity: 1 kg/h
Inlet: W21.7 LH (G2) French
Outlet pressure: 29 mbar
-
Low pressure regulator
Dual stage regulator
With inlet pressure gauge
Level Gauges
Digital Measurement System for Camping
-
For Camping-car
Check level on your smartphone
Alugas or Gaslow cylinder
-
For Camping-car
Level measurement
Connected to the DIMES app
Accessories and Spare Parts
-
Inlet: 35mm, EN15202, fig.G.56
Outlet: W21.8x1/14 LH
-
Plastic protection cap with strap
No pressure tight
-
Safety Valve Spring
26 bar
-
Hose Break Protection
Type 510 - 50 mbar
Connection G 1/4" left
-
-
-
-
-
Adjusting screw
M14,2 x 1
-
Safety Valve Spring
26 bar
-
-
-
-
-
Inlet: Various threads
Outlet: W21.8x1/14 LH
-
Inlet: 27 mm, EN15202 fig. G.59
Outlet: W21.8x1/14 LH
-
Lock nut with seal and strap
-
Red signal cap for valves 425, 426, 452
-
Seal ring for 21.7x1.814-LH-SI for valve 453
-
Compact Adapter for portable LPG tanks
-
-
Inlet: Bayonet
Outlet: CGA 510 - 90° angled or others
-
Safety Relief Valve Holder, Complete
For 412 Valves
-
Valve Insert
With Seal Ring, Complete
-
-
-
-
-
Yellow Cap
SRG 425 Compact Valve
20/21/22 mm
-
Consumer Seal Ring
21/22 mm
-
-
-
-
-
-
Consumer Seal Ring For SRG 428 Bayonet-Valve
-
Plastic protection cap with strap
Pressure tight
230 mm string
