LPG Cylinder Quick-coupling valves
Jumbo
-
Inlet: Various threads
Outlet: 35mm to EN15202
Plastic cap available
-
Inlet: Various threads
Outlet: 35mm to EN15202
Sealed dust plug
-
Inlet: Various threads
Outlet: 35mm to EN15202
Pressure tight cap available
-
Inlet: Various threads
Outlet: 35mm to EN15202
Pressure tight cap available
-
Inlet: Various threads
Outlet: 35mm, EN15202
Monobody
Compact
-
Inlet: Various threads
Outlet: 20, 21 or 22mm to EN15202
Pressure tight platic cap available
-
Inlet: Various threads
Outlet: 20mm, 21mm, 22mm
With sealed dust plug
Snap Tight
-
Inlet: Various threads
Outlet: 27 mm, EN15202
With dust plug
Bayonet System
-
Inlet: 3/4-14 NGT
Outlet: Bayonet connection
Pressure tight plastic cap
Mini Jumbo
-
Inlet: Various threads
Outlet: 16mm to EN15202
Pressure tight plastic cap available
LPG Cylinder Handwheel Valves
LPG Handwheel valves with screwed-type outlet
-
Inlet: W19.8, DIN 477 (17E)
Outlet: W 21 8x1/14 - LH DIN 477
PRV: 26 or 35 bar
-
Inlet: W28.8, DIN 477 (25E)
Outlet: W21.8/1/14-LH DIN 477
PRV: 26 or 35 bar
-
Inlet & outlet: Various threads
PRV: Without pressure relief valve
Excess Flow Rate / Flow limiter
-
Inlet: W19.8 DIN 477 (17E)
Outlet: R3/8-LH DIN 477 No.4
With diptube
LPG Handwheel valves with POL-outlet
-
Inlet: W28.8 DIN 477 (25E), 3/4” NGT
Outlet: 0.885 NGO
PRV: without
-
Inlet: Various threads
Outlet: 0.885 NGO, 5/8“BSP-LH
PRV: Different settings
-
Inlet: ¾”-14 NGT
Outlet: 0.885 NGO
PRV: 420 / 435 / 450 psi
LPG Handwheel Valves with OPD
-
Inlet: ¾“ NPT M 34 x 1,5
Outlet: CGA 510_ 1 5/16“ ACME
PRV: 375 PSI
LPG Cylinder Multivalve
Forklift Cylinder Multivalve
-
Inlet: M34x1 or 1 ¼“ NPT
Fillingport: 1 ¾-6 ACME
Outlet: 3/8“-18 NPT with handwheel
-
Integrated Filling-port 1 ¾-6 ACME
Manual shutoff valve for servicing
Quick filling
LPG Cylinder Safety Relief Valves
Automotive Cylinder Safety relief valves
-
Reference: A1402
Inlet: 1"NPT
Outlet: 1"-20 UNEF
-
Reference: A1451
Inlet: 3/4" NPT
Outlet: 1"-20 UNEF
-
Reference: 146
Inlet: 1"NPT
Outlet: 1"-20 UNEF
-
Reference: A1450
Inlet: 3/4"-14 NPT
PRV: 27 bar
Forklift Cylinder Safety Valve
-
Inlet: 1/4” NPT
Set Pressure: 400 PSI / 27,6 bar
For Forklift tank kits
LPG Cylinder Fillstop Valve
Automotive Cylinder Fillstop valve
-
Inlet: 3/4" NPT
Outlet: 3/4" UNF (1/2"SAE)
Approval: R67.01/CE/UL/CSA
-
Inlet: Euro Connector
Outlet: ¾“-14 NPT
Approval: PI-listed
-
Inlet: 3/4" NPT
Outlet: 1 3/4" ACME
Belgian ACME connection
-
Inlet: 3/4" NPT
Outlet: W21,8x1/14
Dutch BK connection
Forklift Cylinder Fillstop valve
-
Inlet: 3/4" NPT
Outlet: 1 3/4" ACME
Plastic cap available
LPG Forklift Cylinder Valves
-
Compact Clip-on
EN 13155 compliant
Different sizes
-
Compact
Quick Coupling
Angled dip tube
-
Inlet: W 19,8
Outlet: 22 mm
Diptube: R144 angled
-
Inlet: W 19.8 /W28.8
Outlet: W21,8 x 1/14-LH DIN 477
With dip tube
-
Inlet: W19.8
Outlet: G 3/4’’ LH
Dip tube R 125 mm
LPG Cylinder Service Valve
Forklift Cylinder Service Valve
-
Inlet: 3/4”
Outlet: 5/16 SAE
Brass
-
Inlet: 3/4”
Outlet: 3/8”-18 NPT
Further Models available
-
Inlet: 3/8"-18NPT
Outlet: 1 1/4"-5-ACME 2-G
Lift-Truck-Coupling
-
Inlet: 1/4"NPT
Outlet: 1 1/4"ACME
Further models available
LPG Cylinder Filler Valve
-
Inlet: ½” SAE 90°
Euroconnector
Stainless Steel
-
Inlet: ¾ " NPT
Outlet: 1 ¾ "-6 ACME
Opening: Straight opening
