LPG TANK STORAGE MULTIVALVES - 483-500-1-a SERIES
_qMUknk.jpg "LPG TANK STORAGE MULTIVALVES - 483-500-1-a SERIES (1)")
_T8VAcn.jpg)
The SRG 483-500 is a Combo-valve for LP Gas Applications with an integrated, high-flow 85% auto-shut off feature (OPD).
The valve incorporates a Vapor Service Connection 0.885 NGO F-POL with red handwheel, an Occasional Liquid Withdrawal Valve with Connection 1 5/8” UNF with an integrated manual shut off device (no Actuator valve required).
Filling is done through a 1 ¾-6 ACME Connection, High-Flow Filling at more than 180 liters/minute of Liquid Propane (at a delta pressure of 4 bar) with a manual shut-off / auto shut-off Overfill Prevention Device (OPD).
The valve incorporates a Vapor Service Connection 0.885 NGO F-POL with red handwheel, an Occasional Liquid Withdrawal Valve with Connection 1 5/8” UNF with an integrated manual shut off device (no Actuator valve required).
Filling is done through a 1 ¾-6 ACME Connection, High-Flow Filling at more than 180 liters/minute of Liquid Propane (at a delta pressure of 4 bar) with a manual shut-off / auto shut-off Overfill Prevention Device (OPD).
Specifications
| Tank connection | 1 ½” x 11.5 NPT | |
| Filling connection | 1 ¾ - 6 ACME | |
| other | 85% Auto-shut off | |
| Outlet | F-POL 0.885 NGO |
